JEE PYQ: Vector Algebra - Question ID 658c290eaf1e (JEE Main 2024)

ID: 658c290eaf1eJEE Main 2024Numerical Value

Three vectors $\overrightarrow{\mathrm{OP}}, \overrightarrow{\mathrm{OQ}}$ and $\overrightarrow{\mathrm{OR}}$ each of magnitude $\mathrm{A}$ are acting as shown in figure. The resultant of the three vectors is $\mathrm{A} \sqrt{x}$ . The value of $x$ is _________.

JEE Main 2024 (Online) 8th April Morning Shift Physics - Vector Algebra Question 5 English

JEE Question illustration 658c290eaf1e

Your Answer

Step-by-step Explanation

$\begin{aligned} &\begin{aligned} & (\vec{P}+\vec{Q})=\sqrt{2} A \\ & R=A \\ & \theta=90^{\circ} \end{aligned}\\ &\text { Resultant }=\sqrt{3} A \end{aligned}$

View Related Chapter: Vector Algebra Practice Chapter Test (CBT Mode)

Related Questions from Vector Algebra

ID: 24f2d8b8395fJEE Main 2026

The velocity of a particle is given as $\vec{v} = -x \hat{i} + 2y \hat{j} - z \hat{k}$ m/s. The magnitude of acceleration at point (1, 2, 4) is ________ m/s².

View Solution →

ID: f8c378224232JEE Main 2024

The angle between vector $\vec{Q}$ and the resultant of $(2 \vec{Q}+2 \vec{P})$ and $(2 \vec{Q}-2 \vec{P})$ is :

View Solution →

ID: 43173f04f8d9JEE Main 2024

If two vectors $\vec{A}$ and $\vec{B}$ having equal magnitude $R$ are inclined at angle $\theta$ , then

View Solution →

ID: 42a3e5fdc289JEE Main 2023

x-y

plane makes an angle of

30^{\circ}

y

-axis. The magnitude of

\mathrm{y}

-component of vector is

2 \sqrt{3}

. The magnitude of

x

-component of the vector will be :

View Solution →
